Adaptive Technologies Group MultiMount MM-017 25lb Indoor Speaker Wall Mount

Adaptive Technologies Group MultiMount MM-017 Indoor Speaker Wall Mount

The Adaptive Technologies Group MM-017 MultiMount quickly and permanently attaches surround loudspeakers to auditorium walls with full pan, tilt and clockwise rotation, making it easy to aim cinema surrounds.

Its extended arm anchors through sound panels and drapes up to 2.5 in (63.5 mm) deep. It is rated 35 lb (16 kg) at a 5:1 design factor.

Key Features and Highlights

• 35 lb (16 kg) WLL: 5:1 design factor.
• Pan, tilt and rotation: Infinite, no-drift aiming.
• Through panels and drapes: Up to 2.5 in (63.5 mm) deep.
• Mounting patterns: 2.00 x 4.25 in and 2.75 x 5.00 in.
• Weather resistant: Covered outdoor and indoor use.

What's in the Box

• 1 two-axis mount
• 1 flat washer
• 1 screw, 1/4-20 x 1/2 in

Who Is This Product For?

Ideal for: Cinemas and auditoriums mounting surround loudspeakers.

Important: Always install safety cables.

Specifications

• Part Number: MM-017
• WLL (Working Load Limit): 35 lb (16 kg) max
• Design Factor: 5:1
• Mounting Patterns: 2.00 x 4.25 in, 2.75 x 5.00 in
• Panel Depth: Up to 2.5 in (63.5 mm)
• Material: Structural steel alloy, black powder coat
• Net Weight: 1.5 lb (0.7 kg)
