Adaptive Technologies Group Eyebolts & Eyenuts

Adaptive Technologies Group Eyebolts and Eye Nuts

Adaptive Technologies Group drop forged shoulder eyebolts and eye nuts give strong, predictable suspension points for overhead rigging. They are produced in the United States and rated at a 5:1 design factor.

The shoulder spreads side loads into the mounting surface. Ratings drop as the pull moves off vertical, so use the 0, 45 and 90 degree values in the table.

Key Features and Highlights

• Drop forged, made in USA: Consistent, load-rated fasteners.
• Shoulder design: Rated at 0, 45 and 90 degrees.
• Imperial and metric: 1/4-20 to 5/8-11 and M10 threads.
• Black or zinc: Plain SKUs black, -S SKUs bright zinc (silver).
• Eye nuts: EN-375 and EN-500 for threaded rod and bolts.

Who Is This Product For?

Ideal for: Riggers and installers building suspension points on beams, grids and equipment.

Important: Keep side loads within the angle ratings. Several SKUs (EB-500-5.5-S, EB-M10-S, EB-M10-50, EB-M10-50-S, EL-375, EL-625, EN-375-S, EN-500-S) are not on the supplier datasheet; confirm before ordering. Always install safety cables.

Specifications

• Long and Large Eyebolts: EB-500-5.5 (5.5 in shank): 2,200 / 550 / 440 lb; EB-625 5/8-11: 4,000 / 1,000 lb (0 / 45 deg)
• Metric Eyebolts: EB-M10 and EB-M10-18, M10x1.5: 1,628 / 407 / 326 lb
• Eye Nut WLL: EN-375 3/8-16: 1,240 lb (564 kg); EN-500 1/2-13: 2,240 lb (1,018 kg)
• Design Factor: 5:1
• Finish: Black zinc plate; bright zinc plate (-S)
• Made In: USA
